2.4 GHz 300 Mbps 9 dBi Outdoor CPE
Overview A high-performance outdoor CPE designed for reliable long-range wireless connectivity in challenging environments. Operating in the 2.4 GHz band, this unit delivers up to 300 Mbps throughput with a focused 9 dBi antenna for extended coverage beyond 5 km under optimal conditions. Ruggedized and weatherproof, it supports flexible deployment modes and enterprise-grade management features.
Key Specifications
Radio: 2.4 GHz, up to 300 Mbps
Antenna Gain: 9 dBi (integrated)
Range: 5+ km (line-of-sight, environmental and deployment dependent)
Ethernet: 1× 10/100 Mbps shielded RJ-45 port
Power: Passive PoE (included)
Weatherproofing: IPX5-rated enclosure
Throughput Optimization: MAXtream TDMA for collision-free transmission
Deployment Modes: AP, Client, AP Router, AP Client Router
Features and Benefits
Long-Range Performance: The 9 dBi directional antenna and optimized RF design extend reliable connectivity to clients located over 5 km away in line-of-sight scenarios, ideal for rural broadband, tower-to-premises links, and campus backhaul.
High Throughput: Up to 300 Mbps at 2.4 GHz supports bandwidth-intensive applications such as video surveillance, VoIP, and real-time data transfer.
Robust Weather Resistance: IPX5-rated housing protects against water jets and harsh outdoor conditions, ensuring continuous operation in rain and wind.
Simplified Installation: Single shielded 10/100 Mbps Ethernet port with Passive PoE reduces cabling complexity and enables quick site deployments.
Deterministic Access with TDMA: MAXtream TDMA minimizes airtime contention, increases network efficiency, and improves latency for time-sensitive traffic.
Flexible Operation Modes: Configure as an Access Point, Client, AP Router, or AP Client Router to meet varied network topologies and service models.
Centralized Management: Integrates with centralized management platforms for bulk configuration, monitoring, and firmware updates — streamlining lifecycle operations across large deployments.
Spectrum Analyzer: Built-in tools help identify interference sources, optimize channel selection, and troubleshoot RF issues on-site.
Shielded Ethernet Port: Provides robust grounding and EMI protection for outdoor installations.
Use Cases
Last-mile wireless access for underserved or remote areas
Point-to-multipoint links for small to medium-sized enterprises
Wireless backhaul for camera networks and IoT sensor farms
Temporary event connectivity and rapid-deploy network nodes
Rural schools, clinics, and municipal connectivity projects
Physical and Environmental
Form Factor: Compact, rugged outdoor CPE with integrated directional antenna
Mounting: Pole- or wall-mount compatible hardware included
Operating Temperature: Designed for extended outdoor temperature ranges
Ingress Protection: IPX5 (water jets); verify local requirements for dust ingress if needed
What’s in the Box
2.4 GHz Outdoor CPE with integrated 9 dBi antenna
Passive PoE injector and power adapter
Mounting bracket and hardware
Quick start guide and safety information
Management and Security
Centralized management support for remote provisioning and monitoring
Secure firmware update mechanisms and administrative access controls
Traffic prioritization via TDMA and QoS settings for latency-sensitive services
Ordering and Support Available for enterprise and service-provider deployments. Zorins Technologies provides professional services for site survey, installation support, and ongoing managed services to ensure optimal network performance.
Technical note: Actual range and throughput depend on regulatory limits, environmental conditions, antenna alignment, and network configuration. For guaranteed performance, consult a site survey and planning service.
