Omada AX1800 Wall-Plate Dual-Band Wi‑Fi 6 GPON Access Point
Overview A purpose-built wall-plate access point that integrates GPON uplink and Wi‑Fi 6 performance into a low-profile, electrician-friendly form factor. Designed for hospitality, multi‑dwelling units, corporate guest rooms, and premium residential deployments where aesthetic integration, wired backhaul, and centralized management are required.
Key Specifications
Ports: 1× SC/UPC GPON + 2× 1G RJ45 + 1× RJ11 (phone)
Wireless Speed: Up to 574 Mbps (2.4 GHz) + 1201 Mbps (5 GHz) — AX1800 class
Radio/Antennas: Dual‑band Wi‑Fi 6 with 4 internal antennas
Power: AC power (wall‑plate powered)
Standards: 802.11ax (Wi‑Fi 6), backward compatible with 802.11a/b/g/n/ac
Performance & Wireless Features
MU‑MIMO: Simultaneous multi‑client throughput to reduce latency and increase aggregate capacity.
80 MHz channel support: Higher throughput on compatible 5 GHz clients.
Beamforming: Improved link reliability and range by directing RF energy toward connected devices.
Band Steering: Automatically nudges capable clients to the less congested 5 GHz band for optimal performance.
Airtime Fairness & Load Balancing: Prevents slower devices from monopolizing airtime and balances client load across radios and APs.
Seamless Roaming: Fast roaming for uninterrupted voice and video sessions across multiple APs.
Management & Integration
Centralized Management: Full lifecycle control via Omada SDN Controller — provisioning, monitoring, policy enforcement, firmware updates, and analytics from a single pane of glass.
Omada App: Mobile setup, real‑time status, and basic configuration for on‑the‑go administration.
GPON Integration: Direct GPON uplink simplifies deployment where fiber to the room is available; supports service-provider friendly topologies.
Physical & Deployment Notes
Wall‑plate form factor for flush mounting in guest rooms or apartments; preserves room aesthetics while delivering enterprise features.
RJ11 port for analog voice integration where required.
AC-powered design avoids dependency on PoE infrastructure; suitable for retrofits in existing electrical backboxes.
Use Cases
Hotels and serviced apartments: High-density coverage in every room with centralized policy enforcement and seamless guest roaming.
Multi‑dwelling units (MDU): Fiber-fed apartments with in-unit Wi‑Fi 6 performance and voice passthrough.
Corporate offices and meeting rooms: Discreet, high-performance connectivity with centralized IT control.
Why Choose the Omada AX1800 Wall‑Plate AP
Combines GPON flexibility with Wi‑Fi 6 efficiency in a discreet wall‑mounted package.
Enterprise-grade wireless features (MU‑MIMO, beamforming, airtime fairness) for consistent user experience.
Centralized Omada SDN management reduces operational overhead and accelerates deployments.
Ideal for environments that demand both design-conscious hardware and carrier-grade connectivity.
What’s in the Box (typical)
Omada AX1800 Wall‑Plate AP
Mounting hardware and faceplate
Quick installation guide
Safety and regulatory documentation
Ordering & Support Contact your Zorins Technologies representative for SKUs, warranty options, and professional installation services. Technical support and firmware updates are available through the Omada support channels and our enterprise services team.
