POE10R

Overview Compact, reliable power and data separation for devices that lack Power over Ethernet. This pocket-sized PoE splitter adheres to IEEE 802.3af and extracts up to 12V/9V/5V DC from a single Gigabit PoE feed—delivering both power and Gigabit data where you need it most, up to 100 meters over standard Ethernet cabling.

Key Features

• Ports: 1× Gigabit PoE input port, 1× Gigabit non-PoE output port

• PoE Standard: IEEE 802.3af compliant

• Distance: Data and power carried together up to 100 meters (328 ft) over Cat5e/Cat6

• Output Voltages: Selectable 12V, 9V, or 5V DC to accommodate a wide range of devices

• Form Factor: Durable plastic case, pocket-size for simple deployment and transport

• Gigabit Performance: Full Gigabit throughput preserved between PoE source and non-PoE device

• Use Cases: IP cameras, wireless access points, VoIP phones, single-board computers, and other non-PoE devices requiring DC power

Technical Notes

• Power budget depends on the upstream PoE source (switch or injector). Ensure the PoE supply can provide sufficient power for the selected output voltage and the target device’s consumption.

• Maximum cable length for combined power and data is 100 meters. Longer runs may require local power or a higher-power PoE standard.

• Output connector and cable not included; verify polarity and connector type match the powered device before use.

What’s Included

• PoE Splitter Adapter (plastic enclosure)

• Short adapter cable for DC output (where applicable)

• Quick start guide

Applications

• Field technicians needing fast, portable PoE-to-DC conversion

• Retrofit projects converting existing PoE infrastructure to power legacy non-PoE equipment

• Temporary deployments and demos where power outlets are unavailable

Ordering Info Specify required DC output (12V, 9V

PoE Splitter Adapter

Overview Compact, reliable power and data separation for devices that lack Power over Ethernet. This pocket-sized PoE splitter adheres to IEEE 802.3af and extracts up to 12V/9V/5V DC from a single Gigabit PoE feed—delivering both power and Gigabit data where you need it most, up to 100 meters over standard Ethernet cabling.

Key Features

• Ports: 1× Gigabit PoE input port, 1× Gigabit non-PoE output port

• PoE Standard: IEEE 802.3af compliant

• Distance: Data and power carried together up to 100 meters (328 ft) over Cat5e/Cat6

• Output Voltages: Selectable 12V, 9V, or 5V DC to accommodate a wide range of devices

• Form Factor: Durable plastic case, pocket-size for simple deployment and transport

• Gigabit Performance: Full Gigabit throughput preserved between PoE source and non-PoE device

• Use Cases: IP cameras, wireless access points, VoIP phones, single-board computers, and other non-PoE devices requiring DC power

Technical Notes

• Power budget depends on the upstream PoE source (switch or injector). Ensure the PoE supply can provide sufficient power for the selected output voltage and the target device’s consumption.

• Maximum cable length for combined power and data is 100 meters. Longer runs may require local power or a higher-power PoE standard.

• Output connector and cable not included; verify polarity and connector type match the powered device before use.

What’s Included

• PoE Splitter Adapter (plastic enclosure)

• Short adapter cable for DC output (where applicable)

• Quick start guide

Applications

• Field technicians needing fast, portable PoE-to-DC conversion

• Retrofit projects converting existing PoE infrastructure to power legacy non-PoE equipment

• Temporary deployments and demos where power outlets are unavailable

Ordering Info Specify required DC output (12V, 9V, or 5V) when ordering to ensure compatibility with your device. For high-draw devices or distances approaching 100 meters, confirm your PoE source can supply adequate wattage.
