SM9220-1M

Product Overview The Omada 1 Meter 100G QSFP28 Direct Attach Cable delivers high-performance, low-latency connectivity for modern data centers and enterprise networks. Designed for short-reach interconnects, this passive cable supports both 100Gbps and 40Gbps data rates and provides a reliable, cost-effective solution for top-of-rack, spine, and aggregation switch connections.

Key Specifications

• Maximum Length: 1 meter

• Supported Data Rates: 100 Gbps and 40 Gbps

• Compatible Ports: 100G QSFP28 slot and 40G QSFP+ slot

• Interface: QSFP28 to QSFP28 (backward compatible with QSFP+)

• Installation: Plug-and-play, hot-pluggable

• Form Factor: QSFP28 direct attach copper (DAC)

Benefits

• High Throughput: Supports full 100Gbps bandwidth for high-density, bandwidth-intensive applications.

• Backward Compatibility: Seamlessly operates at 40Gbps when connected to QSFP+ ports, enabling flexible upgrades and mixed-speed environments.

• Low Latency: Passive copper design minimizes latency for latency-sensitive workloads such as virtualization, storage, and high-performance computing.

• Cost Efficiency: Economical alternative to optical transceivers for short-distance connections without compromising performance.

• Simple Deployment: Plug-and-play connectivity reduces installation time and operational complexity.

Use Cases

• Top-of-Rack to aggregation switch links in data centers

• High-performance computing clusters requiring low-latency interconnects

• Storage area networks and server-to-switch connections

• Network upgrades where backward compatibility with 40G hardware is required

Mechanical and Environmental

• Cable Length: 1 m

• Connector Type: QSFP28 / QSFP+

• Operating Temperature Range: Standard commercial operating range (refer to device-specific compatibility)

• Compliance: Meets industry mechanical and electrical specifications for QSFP28/QSFP+

Ordering Information

• Product: Omada 1M 100G QSFP28 Direct Attach Cable

• Length: 1 meter

• Model: Omada-QSFP28-DAC-1M

Compatibility Note Verify that your switches, NICs, and network equipment support passive DAC modules and QSFP28/QSFP+ interfaces. Some vendors require specific firmware or compatibility settings for direct-attach copper assemblies.

Packaging and Warranty

• Supplied in protective packaging to prevent connector damage

• Warranty: Standard manufacturer warranty (refer to reseller or Omada warranty terms for details)

For high-density, short-range 100Gbps connectivity with 40Gbps backward compatibility, the Omada 1 Meter 100G QSFP28 Direct Attach Cable offers a straightforward, cost-effective solution
